Recently, a pharmaceutical company which produces an ibuprofen suspension in sugar syrup was having production challenges. The company had been developing a new product with the use of traditional agitators and had been using kaolin, a type of silicate material, to keep the product in suspension and increase stability. Ideally, they wanted to remove the kaolin from the formulation and reduce the ibuprofen particles down to a much smaller size, but this was not possible with their agitator since it did not provide the shear energy needed to reduce particle size.
Agitators Lead to Agitation
Their existing process posed several challenges:
- Due to equipment limitations, creating a premix of water, ibuprofen, kaolin, and a commonly used oral medication emulsifier was necessary.
- Mixing the premix required a lengthy amount of time.
- A separate vessel with an additional agitator was needed to produce a sugar syrup by dissolving sugar into warm water.
- Processing times were prolonged due to the heating of the water for the syrup and subsequent cooling of the sugar syrup before adding to the ibuprofen mixture.
The company was mixing batches of 150 liters but were keen to increase this and remove the kaolin from the formulation. They knew their current process and mixing equipment would make this increase very difficult to achieve, so they contacted Silverson.
The Silverson team recommended conducting trials with an in-tank Batch mixer, having determined it to be the most suitable solution for the application. Yet before a trial could even be arranged, the company learned that their counterpart in Pakistan had already purchased a Silverson mixer—and was achieving excellent results and consistently high-quality products. Confident in the proven performance, the company immediately purchased the recommended Batch mixer.
From Trial to Triumph: Transformative Mixing Results
Once the mixer was delivered, the company used it for this application and the results were significantly better than they had previously achieved with the agitator. The Batch mixer was able to reduce the ibuprofen particles down to between 2-5 microns in a much shorter mixing time, and the sugar solution could be made at ambient temperature, further reducing processing time and costs. The company was able to achieve the desired stable suspension they were aiming for all without the need to add the kaolin.
Does Your Pharmaceutical Mixing Process Need a Boost?
Whether you’re striving to enhance product quality, optimize production efficiency, or navigate regulatory complexities, Silverson is your trusted partner. Contact us today to explore how our mixing solutions can revolutionize your pharmaceutical operations.
